Elan Digital Qualifies World's Smallest Professional Grade USB Oscilloscope on Windows 7

Elan Digital Systems has tested and qualified its highly successful pocket-sized USB oscilloscope on Microsoft Windows 7. The USBscope50 is arguably the smallest professional grade USB oscilloscope in the world.

The USBscope50 has been designed to provide the optimum balance between portability, flexibility, overall performance and cost effectiveness.

Measuring just 75mm x 31mm x 17.5mm and offering DC-75Mhz bandwidth and 1Gsps equivalent time sampling, the device is ideal for most standard test and measurement tasks.

USBscope50 provides equipment and operator safety protection by virtue of its 300v CAT II galvanic isolation.

For the user it can eliminate the need to carry bulky equipment but still be able to quickly and easily diagnose problems either in the field or laboratory. All that is required is PC with USB port, the USBscope50 and a standard scope probe.

The unique snap together stackability of the device allows the user to select the number of channels required.

Java based application software provides a clear, simple and highly functional user interface which is compatible with all major operating systems and now including MS Windows 7.

Picture attached: Elan's USBscope50 has qualified to work in Windows 7 OS

Web link: http://www.elandigitalsystems.com/usb/usbscope50.php

About Elan:

Elan Digital is a privately owned company which has gained unique experience over its 34 year history and uses the latest design & manufacturing technology which makes them one of the leading PC and PDA interface design companies globally. In recent years Elan Digital has expanded its design expertise to include SD/SDIO, USB and Express Card technologies as well as focusing its design efforts on unique products for the fast-growing mobile datacomms market. Elan Digital has ISO9001 (2000) approval.
